The Yamaha Urban Rush is a Class 1, pedal-assist e-bike and goes up to 20mph. You do not need a license to operate a Class 1 e-bike, which makes it an accessible option for all types of riders. If you’ve been looking for a new way to commute, or an affordable way to switch up your transportation routine, the Urban Rush is for you.
The Yamaha Urban Rush electric bike combines the efficiency of a road bike with drop bars and bar-end shifters with Yamaha’s superior power-assist bicycle technology for an unrivaled ride down the open road from a name you can trust.
It is available now for shipping in different colors and sizes. Yamaha Marketplace has brand new and fairly used Yamaha electric bikes in stock, however it is recommended to contact Yamaha Marketplace to confirm color and size availability before ordering as inventory varies from day to day.
Features
Rear Rack Mounts
The built-in bosses on UrbanRush are there to accept Yamaha’s accessory rear rack to help dial in your ultimate commuter.
PWSeries SE Drive Unit
At the heart of UrbanRush is Yamaha’s awesome PWSeries SE center mount drive unit. Integrated to the bottom bracket, the drive unit provides a low center of gravity for exceptional handling. The four levels of power assist assure UrbanRush lives up to it’s name.
Multi-Function Display
Large ergonomic control switches and easy to read LCD multi-function display are designed to keep your focus on what’s ahead. The main LCD interface allows you to choose from a full suite of functions; Speedometer, average speed, maximum speed, odometer, trip meter, battery capacity, battery range, cadence, clock and stopwatch.
Hydraulic Disc Brakes
Shimano Tiagra hydraulic disc brakes with 160mm center lock rotors ensure strong, confident braking in all conditions. Speaking of all conditions, UrbanRush’s fork has mounting tabs for easy installation of Yamaha’s accessory front fender.
Tiagra Groupset
Shimano’s durable 10-speed Tiagra groupset handles UrbanRush’s shifting duties. The double chainring (50/34T) ensures optimum gear range to conquer any climb your commute presents with ease.
LED Headlight
We equipped Yamaha Urban Rush with a powerful LED headlight to help guide the way. The headlight’s on/off button is built into UrbanRush’s multi-function display housing for easy access while riding.
Fender Mount Tabs
The fork on Yamaha Urban Rush has built-in mounting tabs for easy installation of Yamaha’s accessory front fender.
Integrated Speed Sensor
Exclusive to Yamaha Power Assist Bicycles is a speed sensor engineered into the rear hub. Our speed sensor recognizes the slightest change in bicycle speed and helps adjust motor input to deliver a smooth and natural power assist feel for the ultimate ride experience.
Yamaha 500Wh Battery
Yamaha Urban Rush has a 500 Watt-hour Lithium-ion battery pack that provides reliable & long lasting energy to power your rides. When it’s time to replenish, you can charge the battery pack on or off Urban Rush using the Yamaha high speed charger.
Yamaha Urban Rush Specifications
| Suggested Use | :Road, Urban Bike Path |
| Size | :S 53cm, M 55cm, L 58cm |
| Frame | :Yamaha hydroformed and butted alluminum. |
| Fork | :Aerodynamic alloy. 12mm thru-axle. Fender compatible. Internal hose routing . 1 1/8in dia |
| Battery | :Side exit Yamaha 500Wh 36V Lithium-Ion |
| Motor | :PWSeries SE 3-bolt mount |
| Crankarm | :Square taper. 165mm (53cm). 170mm (55cm and 58cm) |
| Chainring(s) | :50/34T E-Ring 110 BCD |
| Shifters | :Shimano Tiagra Hydraulic Disc Brake Dual Control Lever 2×10 (STRS405) |
| Front Derailleur | :Shimano Tiagra (2 x 10) Braze-on |
| Rear Derailleur | :Shimano Tiagra RD-4700 GS 10-Speed |
| Brakes/Rotors | :Shimano Tiagra BR-RS405 Hydraulic Disc 160mm SM-RT68 Centerlock Rotor |
| Cassette | :Shimano 11/32T |
| Chain | :KMC X10e |
| Hubs | :Front: 12 x 100 TA. Rear: 12 x 142, Shimano freehub, Integrated speed sensor, Centerlock |
| Rims | :700c Aero alloy rim. 27mm depth. Rim width: 22.2mm (OUTSIDE) 17MM (INSIDE) |
| Spokes | :Spokes SUS304 |
| Spoke Nipples | :Brass |
| Tires/Tubes | :CST XPEDIUM AMPERO (700 x 35c). Level-5 flat protection. Reflect sidewall. PV Tube |
| Headset | :Integrated headset with 30mm headset spacers |
| Stem | :4-bolt faceplate. 31.8 diameter. 80mm length (53cm, 55cm). 100mm length (58cm) |
| Handlebar | :Alloy drop bar. 31.8mm diameter. 40cm width (53cm). 42cm (55cm and 58cm) |
| Grips/Tape | :Padded cork tape |
| Seatpost/Saddle Clamp | :Alloy 30.9 x 260mm(S),315mm(M),350mm(L) with 2-bolt adjustable tilt saddle rail clamp |
| Seatpost Collar | :Alloy 2-bolt 35.0mm |
| Saddle | :Yamaha Road Plus Cro-Mo Rail |
Yamaha Urban Rush Geometry Frame
| SMALL | MEDIUM | LARGE | |
| Top tube (effective) | 530 | 550 | 580 |
| Reach length | 373 | 392 | 405 |
| Stack height | 548 | 555 | 572 |
| Stand over height | 725 | 751 | 797 |
| Head tube length | 130 | 135 | 150 |
| Head tube angle | 71 | 72 | 72.5 |
| Seat tube angle | 74 | 72 | 73 |
| Seat tube length | 430 | 463 | 530 |
| Bottom bracket drop | 6,1 | 61 | 61 |
| Wheelbase | 1039 | 1051 | 1064 |
| Rear center | 4,55 | 455 | 455 |
Sizing and fit
| Small | 58cm – 170cm1 |
| Medium | 168cm – 179cm |
| Large | 176cm – 187cm |
Yamaha Urban Rush Warranty
3-Year Warranty: Frame, Motor, Battery
*Component manufacturer’s warranty by Yamaha*full details on warranty sheet
