EXPLORE THE SPORTSMAN 850 LINE-UP
Meet the ATV that defined a category. The Sportsman 850 continues the tradition of do-it-all capability and toughness, with power that packs a punch and suspension to tame even the wildest terrains.
- 78-Horsepower ProStar Engine with EFI
- Industry-Leading On-Demand All-Wheel Drive
- 11.5” of Ground Clearance
- Industry’s Largest 30 A.H. Battery
- 360 lb Front and Rear Rack Capacity
POWER THROUGH THE ELEMENTS
There’s nothing like the wide-open feeling you get from a Sportsman. The power, traction and ground clearance to tame the wildest terrain and always stay in control.
- High-Output 78-Horsepower Engine
- Industry-Leading On-Demand All-Wheel Drive
- 11.5” of Ground Clearance
START YOUR DAY WITH CONFIDENCE
Take charge with the assured capability of the 850. The industry’s largest cranking amp battery to get you started in extreme weather and force to tow the biggest hauls.
- Powerful 30 A.H. Battery
- 1,500 lb. Towing Capacity
- 360 lb. Front and Rear Rack Capacity
THRILL RIDES HAVE NO CURFEWS
Ride on your terms, day or night with the added visibility of a third handlebar-mounted pod light and brilliant white LED lower lights. An easy-to-read LED digital display system allows you to track your vehicles progress with just a glance.
FACTORY CHOICE PACKAGES
Factory-choice packages tailor your Sportsman for improved trail performance. Get the confidence of factory-installation while saving time and money.
Trail Package
Your passion for trail riding shouldn’t be limited and neither should your ATV. The NEW package offers 3,500 Polaris HD winch, bumpers and painted springs.
Sportsman 850 Premium
Includes
- Automotive Style Paint
- 26″ CST Tires with 14″ Cast Aluminum Wheels
- Standard Sport Tuned Electronic Power Steering (EPS)
- Standard Engine Braking System (EBS) with Active Descent Control (ADC)
- High-Performance True On-Demand AWD
- 4 Modular Rack Extenders with Lock & Ride
- Factory-Installed Fender Flares
Details
| Status: |
New |
| Vehicle: |
2021 Polaris Sportsman 850 Premium |
| Model Number: |
A21SXE85AF |
| Fuel Type: |
Gasoline |
| Transmission: |
Manual |
| Color: |
Matte Orange Rust |
| Location: |
ATV Zone, LLC |
| Warranty: |
Manufacturer’s w/ Extended Available |
Specifications
BRAKES
| Front Brake Type: |
Hydraulic Disc |
| Rear Brake Type: |
Hydraulic Disc |
DRIVE LINE
| Differential Lock Location: |
Rear |
| Driveline Brand: |
On-Demand™ |
| Driveline Type: |
Selectable 4X2 / 4X4 |
| Limited Slip Differential Location: |
Rear |
| Number Of Driveline Modes: |
2 |
ENGINE
| Bore (in): |
3.43 |
| Bore (mm): |
87 |
| Carburetion Brand: |
Mikuni |
| Carburetion Type: |
Fuel Injected |
| Compression Ratio: |
11 |
| Cooling: |
Liquid |
| Cylinders: |
2 |
| Displacement (cc): |
850 |
| Displacement (ci): |
51.9 |
| Engine Brand Name: |
ProStar™ |
| Engine Stroke: |
4-Stroke |
| Engine Type: |
Parallel Twin |
| Fuel Injector Size (mm): |
42 |
| Fuel Injector: |
Yes |
| Fuel Requirements: |
Regular |
| Fuel Type: |
Gas |
| Horsepower (bhp): |
78 |
| Horsepower (kW): |
57.5 |
| Starter: |
Electric |
| Stroke (in): |
2.81 |
| Stroke (mm): |
71.5 |
| Valve Configuration: |
SOHC |
| Valves Per Cylinder: |
4 |
| Valves: |
8 |
EXTERIOR
| Bash Plate (Front): |
Yes |
| Body Material: |
Composite |
| Floor Board Location: |
Driver |
| Frame: |
Steel |
INSTRUMENTATION
| Fuel Level Warning Type: |
Gauge |
| Temperature Warning Type: |
Gauge |
LIGHTS
PRICING
| Warranty (Condition): |
Limited |
| Warranty (Months): |
6 |
SEATS
| Number Of Seats: |
1 |
| Seat Height (in): |
37 |
| Seat Height (mm): |
940 |
| Seat Location: |
Driver |
| Seat Material: |
Vinyl |
| Seat Type: |
One-Piece |
STEERING
| Steering Control: |
Handlebar |
| Steering Type: |
Power |
STORAGE
| Capacity (kgs): |
110 |
| Capacity (kgs): |
55 |
| Capacity (lbs): |
120 |
| Capacity (lbs): |
240 |
| Number Of Cupholders: |
1 |
| Rack Rails Location: |
Rear |
SUSPENSION
| Front Suspension Type: |
Independent Double A-Arm |
| Front Travel (in): |
9 |
| Front Travel (mm): |
229 |
| Number Rear Shock Absorbers: |
2 |
| Rear Suspension Material: |
Steel |
| Rear Suspension Type: |
Independent Double A-Arm |
| Rear Travel (in): |
10.3 |
| Rear Travel (mm): |
260 |
TECHNICAL SPECIFICATIONS
| Dry Weight (kg): |
357 |
| Dry Weight (lbs): |
785 |
| Engine Displacement to Weight (cc): |
0.92 |
| Fuel Capacity (gal): |
5.3 |
| Fuel Capacity (l): |
19.9 |
| Ground Clearance (in): |
11.5 |
| Ground Clearance (mm): |
292 |
| Height (in): |
50.8 |
| Height (mm): |
1289 |
| Length (ft): |
6.94 |
| Length (ft/ft): |
6 |
| Length (ft/in): |
11.3 |
| Length (in): |
83.3 |
| Length (mm): |
2114 |
| Payload Capacity (kgs): |
261 |
| Payload Capacity (lbs): |
575 |
| Towing Capacity (kgs): |
680.4 |
| Towing Capacity (lbs): |
1500 |
| Wheelbase (in): |
53 |
| Wheelbase (mm): |
1346 |
| Width (in): |
47.6 |
| Width (mm): |
1209 |
TOWING & HAULING
| Rear Hitch Type: |
Receiver |
| Size (cm): |
3.2 |
| Size (in): |
1.25 |
TRANSMISSION
| Hi / Low Range: |
Yes |
| Primary Drive (Engine / Transmission): |
Belt |
| Primary Drive (Front Wheel): |
Shaft |
| Primary Drive (Rear Wheel): |
Shaft |
| Reverse: |
Yes |
| Transmission Brand: |
Polaris Variable Transmission (PVT) |
| Transmission Type: |
Continuously Variable (CVT) |
WHEELS & TIRES
| Front Tire (Full Spec): |
CST® 26 x 8-14 |
| Front Tire Diameter (in): |
26 |
| Front Tire Width: |
8 |
| Front Wheel Diameter: |
14 |
| Rear Tire (Full Spec): |
CST® 26 x 10-14 |
| Rear Tire Diameter (in): |
26 |
| Rear Tire Width: |
10 |
| Rear Wheel Diameter: |
14 |
| Tire Brand: |
CST® |
| Wheels Composition: |
Aluminum |
